IDNR                                                        00001133

BSTNEU                                                  2000-A-2-40,0-EE-RG-GM88-B-F

BSTALT                                                   C-2000-A-040,0-E-RGGM88-B*F*00-2-000

BEZ                                                         2/2-way-piston-operated angle-seat valve

Type (TYP)                                               2000 - 2000

Control function (SF)                                A - closed by spring force

Paths/positions (WS)                                2 - 2 ways / 2 position

Orifice size (DN)                                       40,0 - 40mm (1 1/2")

Seal material (DWST)                                EE - PTFE

Body material (WKST)                               RG - gunmetal

Port connection (LTA)                               GM88 - G1 1/2 threaded port

Actuator version (ANTA)                            B - PA-actuator, MS-threaded bus hing at

connection of pilot air

Actuator size (ANTG)                                F - Dm  80mm

SUBSTID                                                 00178695

CE_KZ                                                     CEEX

LIEFZ                                                       28

Technical Data

PRESS. MAX. (BAR) (DRMAXBAR)                                                      9

PRESS MAX. (PSI) (DRMAXPSI)                                                          130

PRESS. MIN. (BAR) (DRMINBAR)                                                         0

PRESS. MIN (PSI) (DRMINPSI)                                                             0

REQUIRED PILOT PRESS.F.MAX.FLUID PRESS.(BAR) (STDRERFBAR)

REQUIRED PILOT PRESS.F.MAX.FLUID PRESS.(PSI) (STDRERFPSI)

PILOT PRESS. MAX (BAR) (STDRMAXBAR)                                         10

PILOT PRESS MAX. (PSI) (STDRMAXPSI)                                            145

PILOT PRESS. MIN. (BAR) (STDRMINBAR)                                           5

PILOT PRESS. MIN. (PSI) (STDRMINPSI)                                              72

KV-VALUE (M*3/H) (KV)                                                                       38.0

QNN-VALUE (L/MIN) (QNN)

WEIGHT (KG) (MASSE)                                                                        3.50

FLUID TEMP. MAX. (DEGREE C) (MEDTEMPMAX)                              +180

FLUID TEMP. MIN. (DEGREE C) (MEDTEMPMIN)                                 -10

AMB. TEMP. MAX. (DEGREE C) (UMGTEMPMAX)                               +60

AMB. TEMP. MIN. (DEGREE C) (UMGTEMPMIN)                                  -10

ID: 00001133                2000-A-2-40,0-EE-RG-GM88-B-F

1            00208689      1               Actuator for angle-seat valve 2/2-way        19930201      2000BG01

2            00647558      1               Housing DN40 G11/2 CUSN                                          19930201             2000-F1-00647558

3            00631088      1               Seal DN40                                                                    19930201             2000-F1-00631084

4            00900625      2               Plug for G1/4                                                               19930201             0006-8047

5            00637226      1               Label  38,1 x 19,05                                                      19930201             0480-0233-000-00

6            00671761      1               KLEBESCH. EX II 2G/D T4/ =135 CE 65x9                     19930201             2100-F1-00671761

100        00810013      1               BETRIEBSANLEITUNG 2000 A5 QS                               19930201             00462-2111-92002
