| Type |
0127 |
|
| Valve construction |
Valve complete |
|
| Valve function manual actuation |
No |
|
| Valve diameter |
1,6 |
mm |
| Media separation |
Yes |
|
| QNn value (gas) |
49 |
l/min |
| Kv value (water) |
0,045 |
m3/h |
| Differential pressure max |
2 |
bar |
| Nominal pressure min |
0 |
bar |
| Nominal pressure max |
2 |
bar |
| Actuator type |
Rocker |
|
| Switch function |
on/off |
|
| Valve function |
A - normally closed - inlet port 1 (P/NC) |
|
| Fluidic port connection number |
2 |
|
| Valve function number of switching positions |
2 |
|
| Operation |
direct-acting |
|
| Port connection 1 type |
Flanged |
|
| Port connection 1 flange |
Bürkert flange 16 x 27 version C3 |
|
| Port connection 2 type |
Flanged |
|
| Port connection 2 flange |
Bürkert flange 16 x 27 version C3 |
|
| Switch time open characteristic |
25 |
ms |
| Switch time close characteristic |
25 |
ms |
| Nominal operation/Duty cycle |
100 |
% |
| Coil type |
permanently integrated |
|
| Coil insulation material (encasement) |
Epoxy |
|
| Coil wiring LED |
Yes |
|
| Coil wiring overvoltage protection |
Varistor |
|
| Coil wiring rectifier |
Yes |
|
| Coil wiring polarity protection |
No |
|
| Coil wiring polarity recovery diode |
No |
|
| Coil wiring polarity recovery diode redundant |
No |
|
| Coil cover colour |
transparent |
|
| Rated power DC |
3,5 |
W |
| Rated power consumption |
3 |
W |
| Power reduction integrated |
No |
|
| Installation width (nominal value) |
16 |
mm |
| Electrical connection sort |
Power connector for plug Type 1054 and 1057 |
|
| Electrical connection number of contacts |
2 + Grounding conductor |
|
| Cable plug in delivery |
mounted |
|
| Cable plug art. no. - type |
00627426 - 1054 |
|
| Electrical connection position |
top |
|
| Electrical connection polarity |
Irrelevant |
|
| Voltage / rated voltage |
24 |
V |
| Voltage / rated voltage |
24 |
V |
| Voltage frequency |
50/60 |
Hz |
| AC voltage |
Yes |
|
| DC voltage |
Yes |
|
| Battery voltage |
Yes |
|
| Temperature environment min |
5 |
°C |
| Temperature environment max |
55 |
°C |
| Temperature medium min |
5 |
°C |
| Temperature medium max |
50 |
°C |
| Mounting type |
Metric screws |
|
| Mounting dimensions |
M2,5 |
|
| Mounting (flange) type |
Metric screws |
|
| Mounting (flange) material |
Stainless steel |
|
| Fluidics body material |
PVDF (Polyvinylidene fluoride) |
|
| Seat seal material category |
Elastomer |
|
| Seat seal material |
FKM (Fluor rubber) |
|
| Sealing toward outside material |
FKM (Fluor rubber) |
|
| Port connection seal material design |
O-ring |
|
| Valve material medium-contacting |
PVDF (Polyvinylidene fluoride) |
|
| 重量 |
0,064 |
kg |
